Your Lateral Flow Reader



iPeak® expands its family with the iPeak®+, colorimetric lateral flow reader for your large cassettes, up to 7 lines in one strip and up to 5 strips in one cassette with the essence of the  iPeak®. With the breakthrough Flash Eye Technology, iPeak®+ is the perfect match for reading your cassettes, enhancing the colors of your strip, and removing the subjectivity of the eye human.  When the human eye cannot see the lines, the iPeak® can do it.

iPeak®+ is also available for OEM full customization

IUL offers iPeak® technology for full OEM customization in different fields of application, e.g. Environmental and Industrial Microbiology, Medical, or Veterinary. With its ultimate 3D printing prototyping and manufacturing technology, iPeak® can customize, fast, flexible and affordable with minimal time-to-market and good value for money.

Do you want to brand your iPeak®+?

Point-of-care   |   Health & Veterinary Diagnostics   |   Food Safety   |   Drug testing   |   Environmental   |   Research

Change the colors and logos of your iPeak®+ are also available.

With the sensitivity and technology of the iPeak®.

Flash Eye Technology is the combination of excellence in image acquisition and processing and the IUL’s know-how. Flash Eye technology enables to enhance the colors of any colorimètric lateral flow test with an outstanding dynamic range for visual, qualitative, and quantitative assays.

iPeak® brings a camera that captures the image of the test illuminated from LED lights situated in the most studied geometry which allows a precise and uniform illumination. This technology avoids reflections and shadows diffusing and homogenizing the light in a chamber which makes iPeak®’s the best rapid test reader. Know more about this technology here.

Data exportation and Traceability

The results and images of the test are stored in the iPeak®+ internal memory and can be printed or exported by various means (USB memory, or Ethernet/Wi-Fi) following the secure HL7 protocol, the most used in hospital environments). Its barcode reader – which also reads QR or Datamatrix -allows quick identification of the sample.

Export the results to your server via SFTP, whenever and wherever the testing is performed.

Performance

Internal memory16 Gb
Stored resultsResults, raw, and processed images. Depending on int. memory
Number of test lines per stripUp to 7 lines / strip
Up to 5 strips
Measurement time15 seconds, one strip, 2 lines
LanguagesEspañol, English, Deutsch, Français, Italiano, Polski,  العربية



Download the specifications

Technical specifications

ConnectivityWiFi, Ethernet, and LAN, Port USB for printer or export results
Sample traceabilityDatamatrix, QR, and barcode
Battery4h autonomy
Power range100-240 V
Frequency range50-60 Hz
Maximum power18 W
Air temperature15-35ºC
Relative humidity15-75%
Place of operationFor indoor use only
Maximum dimensions of the cassete (LxWxH)Up to 80 x 56 x 6mm / 3.2 x 2.2 x 0.2 in
Dimensions (LxWxH)
Including Tray
150 x 140 x 185 mm / 5.9 x 5.5 x 7.2 in
Weight900g / 1.98lb
ScreenColor, capacitive, 4.3’’ touch screen

Partners that are using our technology

Do you want to know how iPeak®+ can improve your lab workflow?
